Continues bending radius changes during the movement of current of cranes / hoists or lifts are made easy with Axelon Multicore Flat Flexible Cables which have been designed to meet the demand for high flexibility needed for these applications. These cables have been put to rigorous testing to meet internationally accepted specification for such applications.
Bunched construction of Annealed Bare Copper, Class 5 of Electrolytic Grade of IS 8130: 1984.
Specially formulated PVC compound IS 5831 to give glossy finished core with high flexibility.
Special Thermoplastic Material IS 5831 to give glossy finished sheath with high flexibility.
Special knurled surface finish throughout the width of the cable for flat and knurled stripe is given for Round Multicore Flexible Cables to give unique identification.
Flat as well as Round Multicore Flexible Cables can be offered from 3 cores to maximum 10 cores from sizes 0.5 sq.mm to 4 sq.mm and 3 core, 4 core upto 12 cores in sizes 6 sq.mm to 10 sq.mm.
Temperature of the Conductor
-15°c to +70°c.
Identification of Cores
For 5 cores & above black insulation & core number printed in white ink. For up to 4 Cores, core colours as per colour coding Red, Yellow, Blue and Yellow / Green.
Generally Black / Grey. Any other colour required will be against bulk orders.
100 mtrs in coils or 500 mtrs or 1000 mtrs. Drums supply for certain sizes.
Size Dimensions & Ratings
|Nom. Area of Conductor sq. mm||No. Dia of Strands mm*||Thickness of insulation mm||Nom. Thickness of Sheathing mm||Maximum Overall Dimension in mm|
|3 Core||4 Core||6 Core||7 Core||10 Core||12 Core|
